Specifications
|
ASYG09LLCC
|
|
Operation Type
|
(C/H)
|
|
Rated output Btu/h
|
9000
|
|
Cooling performance Btu/h
|
3071 – 10236
|
|
Thermal performance Btu/h
|
3071 – 12966
|
|
Cooling Energy Class
|
A++
|
|
Middle Zone Heating Energy Class
|
A+
|
|
Warm Zone Heating Energy Class
|
Α+++
|
|
Seasonal Energy Efficiency Rating (SEER) (cooling)
|
6,90
|
|
Seasonal Coefficient of Performance (SCOP) Middle Zone (Heating)
|
4,00
|
|
Seasonal Coefficient of Performance (SCOP) Warm Zone (Heating)
|
5,10
|
|
Dehumidification l/h
|
1,3
|
|
Energy consumption kWh per year (cooling)
|
127
|
|
Energy consumption kWh per year (heating)
|
805
|
|
Recommended for spaces up to m2
|
16 – 20
|
|
Noise Level dB(A)Lp (H/M/L/Q) Indoor Unit
|
43/38/33/22
|
|
Indoor Unit Sound Power dB(A)Lw (cooling)
|
59
|
|
Noise Level dB(A)Lp (H) Outdoor Unit
|
47
|
|
Outdoor Unit Sound Power in dB(A)Lw (cooling)
|
61
|
|
Air Supply m3/h (High) Indoor / Outdoor
|
720 / 1670
|
|
Dimensions (H x W x D) mm
|
262x820x206
|
|
Outdoor unit dimensions (H x W x D) mm
|
535x663x293
|
|
Weight of Indoor Unit / Outdoor Unit kg
|
7 / 24
|
