FUJITSU INVERTER ASYG-09KPCE

Home page \ Products \ Air Conditioners \ FUJITSU \ FUJITSU AIR CONDITIONERS \ KP SERIES \ FUJITSU INVERTER ASYG-09KPCE

Available upon request at 1 days

There are 0 products in cart

Quantity:

Rated Output Btu/h: 9000
Cooling Energy Class: A++
Heating Energy Class (Warm Zone): A+++
Heating Energy Class (Middle Zone): A+
Warranty: 10 years for the compressor and 3 years for all parts

Specifications

Rated Output Btu/h	9000
Cooling Energy Class	A++
Heating Energy Class (Heat Zone)	A+++
Heating Energy Class (Middle Zone)	A+
Warranty	10 years for the compressor and 3 years for all parts
Technology	Inverter
Operation Type	C/H
Wi-Fi function	Optional
Wi-Fi Module code	UTY-TFSXF2
Operating Voltage V-Hz-Ph	230V, 50Hz, 1Ph
Cooling Efficiency Btu/h	8500(3071-10236)
Cooling Efficiency kW	2.5(0.9-3.0)
Thermal Efficiency Btu/h	9554(3071-12966)
Thermal Efficiency kW	2.8(0.9-3.8)
Seasonal Energy Efficiency Rating (SEER) Cooling	6.70
Seasonal Coefficient of Performance (SCOP) Heating (Average)	4.00
Seasonal Coefficient of Performance (SCOP) Heating (Heat)	5.10
Dehumidification L/h	1.3
Indoor Unit Noise Level dB(A) (H/M/D/H)	45/38/31/22
Indoor Unit Sound Power dB(A)	58
Outdoor Unit Noise Level dB(A) (H)	47
Outdoor Unit Sound Power in dB(A)	59
Air Supply m³/h (H/M/D) Indoor	580/-/-
Air Supply m³/h (H) External	1650
Energy Consumption kWh Annually (Cooling)	131
Energy Consumption kWh Annually (Heating)	840
R32 content	0.55
Prepaid Liquid	15
Indoor Unit Dimensions (H x W x D) mm	270 x 784 x 224
Outdoor Unit Dimensions (H x W x D) mm	541 x 663 x 290
Net Weight of Indoor Unit Kg	8
Net Weight of Outdoor Unit Kg	23
Diameter of Liquid/Gas Piping mm	6.35(1/4)/9.52(3/8)
Total Piping Length/Height Difference m	20 - 15
Temperature Range	-10~46/-15~24
Coolant Liquid	R32
