Functions and Features
The M-Thermal Arctic Series All DC Inverter heat pump with environmentally friendly refrigerant R32 is suitable for increased power requirements in heating - cooling and domestic hot water production.
A built-in water tank is included for installation flexibility and Wi-Fi for control from anywhere. Suitable for applications with water temperature up to 60 °C.
Technical characteristics
|
Type |
M thermal A Series Mono |
|||
|
Power Supply (Ph-V-Hz) |
380-415/3/50 |
|||
|
Heating Capacity (kW, Evaporator air in 7°C, 85% R.H., Condenser water in out 30 35°C) |
18~30.1 |
|||
|
Heating Capacity (kW, Evaporator air in 7°C, 85% R.H., Condenser water in out 40 45°C) |
18~30 |
|||
|
Heating Capacity (kW, Evaporator air in 7°C, 85% R.H., Condenser water in out 47 55°C) |
18~30 |
|||
|
Cooling Capacity (kW, Condenser air in 35°C. Evaporator water in out 23 18°C) |
17~30 |
|||
|
Cooling Capacity (kW, Condenser air in 35°C. Evaporator water in out 12 7°C) |
18.5~31 |
|||
|
Net dimensions (W×H×D)(mm) |
1129×1558×528 |
|||
|
Packed dimensions (W×H×D)(mm) |
1220×1725×565 |
|||
|
Net weight(kg) |
177 |
|||
|
Gross weight(kg) |
206 |
|||
|
Ambient temp.operation range(Cooling)(℃) |
-5~43 |
|||
|
Ambient temp.operation range(Heating)(℃) |
-25~35 |
|||
|
Ambient temp.operation range(DHW)(℃) |
-25~43 |
|||
 |
