Functions and Features
Energy Class: A+++, with COP up to 5.15
Water Temperature: Up to 65°C
Control: Wired control – room thermostat with built-in Wi-Fi
Technology: All DC Inverter
Refrigerant: R32 with GWP reduced by 75%
Technical characteristics
|
Type |
M thermal A Series Mono |
|
|
|
Power Supply (Ph-V-Hz) |
380-415/3/50 |
||
|
Heating Capacity (kW, Evaporator air in 7°C, 85% R.H., Condenser water in out 30 35°C) |
12.1~16 |
||
|
Heating Capacity (kW, Evaporator air in 7°C, 85% R.H., Condenser water in out 40 45°C) |
12.3~16.0 |
||
|
Heating Capacity (kW, Evaporator air in 7°C, 85% R.H., Condenser water in out 47 55°C) |
12~16.0 |
||
|
Cooling Capacity (kW, Condenser air in 35°C. Evaporator water in out 23 18°C) |
12.~14.9 |
||
|
Cooling Capacity (kW, Condenser air in 35°C. Evaporator water in out 12 7°C) |
11.6~14.0 |
||
|
Net dimensions (W×H×D)(mm) |
1118×864×523 |
||
|
Packed dimensions (W×H×D)(mm) |
1180×890×560 |
||
|
Net weight(kg) |
112 |
||
|
Gross weight(kg) |
125 |
||
|
Ambient temp.operation range(Cooling)(℃) |
-5~43 |
||
|
Ambient temp.operation range(Heating)(℃) |
-25~35 |
||
|
Ambient temp.operation range(DHW)(℃) |
-25~43 |
||
 |
